Description
SUMMARY
Process the onion leaves before harvesting at once.
Contributes to efficiency in picking up, transporting, and drying processes.
By processing the stems and leaves before picking up by the Onion Picker, the onion capacity of the container is increased.
In addition, the drying time of onions can be significantly reduced.
VIDEO
SPECIFICATIONS
1 ridge for 4 rows in 1 stroke
4 rows on a bed of onion stems and leaves can be cut in 1 process.
Dividing belt and raising belt
Fallen stems and leaves are raised and cut by the dividing belt and the raising belt.
Uses clipper type blades
Cut the stems and leaves cleanly.
Uses a spiral auger
Distribute the cut stems and leaves in two rows to the left and right and discharge them.
Since it does not drop on the ridge, post-work is smooth.
ADAPTIVE RIDGE SHAPE
OPTIONAL ATTACHEMENTS
Digging attachment
Undercutting attachment
SPECIFICATIONS
| Model | HT40K | ||||
|---|---|---|---|---|---|
| Dimensions | Length (mm) | 2045 | |||
| Width (mm) | 1500 | ||||
| Height (mm) | 1350 | ||||
| Weight (kg) | 492 | ||||
| Engine | Model name | GB131LN | |||
| Type | Air-cooled 4-stroke gasoline engine | ||||
| Rated output/rotational speed (kW {PS}/min-1) | 2.3 {3.1}/1800 | ||||
| Fuel used | Unleaded gasoline for automobiles | ||||
| Fuel tank capacity (L) | 2.5 | ||||
| Starting method | Recoil starter type | ||||
| Driving part | Crawler | Width x ground length (mm) | 110 x 895 | ||
| Center distance (mm) | 1390 | ||||
| Average ground pressure (kPa {kgf}/cm2) | 24.5 {0.25} | ||||
| Gear shift system | Stepped gear/belt tension | ||||
| Number of gears (steps) | 4 forwards, 2 backwards | ||||
| Working speed | Low speed | Forward | F1 (m/s) | 0.15 | |
| F2 (m/s) | 0.43 | ||||
| Backward | R1 (m/s) | 0.17 | |||
| High speed | Forward | F1 (m/s) | 0.23 | ||
| F2 (m/s) | 0.69 | ||||
| Backward | R1 (m/s) | 0.27 | |||
| Raising part | Cutting number (rows) | Four | |||
| Row spacing (mm) | 250 | ||||
| Leaf cutting height (mm) | 100 to 150 | ||||
| Cutting blade to raising tine height (mm) | 75, 100, 125 | ||||
| Raising method | Tine belt | ||||
| Reaping part | Harvester type | Reciprocating blade type | |||
| Adapted crop | Onion | ||||
| Applicable ridge height (mm) | 50 to 300 | ||||
| Applicable ridge width | Top width (mm) | 900 to 1000 | |||
| Bottom width (mm) | 1200 or less | ||||
| Plastic mulch availability | None | ||||
| Applicable row spacing (mm) | 240 to 250 | ||||
| Applicable row number | 1 ridge 4 rows | ||||
| Work efficiency (calculated value) (hour/10a) | 1.1 to 2.0 | ||||
