SUMMARY
The straight-set nozzle makes this item ideal for spraying onto high-positioned targets. Air-assisted fine spray with minimal drift;switching between far and near targets can be done easily at the grip. To prevent loosening, the lock cap was adopted.
FEATURES
- KIRINASHI (Ultra Low-Drift) Z Boom Sprayer
- To save pesticides
- Drift-reducing
SPECIFICATIONS
| Nozzle # | N-KZV-20 |
|---|---|
| Average Drop Size (μm) | 380?`710?i1.5MPa?j |
| Pressure Range (MPa) | 1.0?`1.5 |
| Code No. | 14 12 83 |
|---|---|
| Product Name | Kirinashi (Ultra Low-Drift) Z Boom Sprayer S 90 |
| Press | 5.8-7.2 l/min?i1.5MPa?j |
| Maximum Spray Reach | approx. 4-9 m |
| Coverage | approx. 15-80cm |
| Spray Angle (1.5MPa) | approx. 15-70° |
| Length/Weight | 96cm?E470g |
| Adapter | G1/4 |
# Coverage as of 1m from nozzle head
