SUMMARY
TAIKI E-20H is a food dryer that easily dries vegetables and fruits. Dried radishes, banana chips, dried persimmons, etc. can be easily made. Farmers can make effective use of out-of-spec products and surplus produce. It enables them to process and taste seasonal foods and to preserve them for a long time.
Corrosion-resistant material (SUS304) Cleaning trays are also standard.
FEATURES
The cleaning tray is also included as a standard feature, reducing drying time and power consumption
The heat source unit was developed in-house in pursuit of thermal efficiency and is equipped with a double-sided blowout system.
Energy efficiency has been improved by about 15% compared to conventional equipment.
Easier to operate, easy to see circulation function damper
Moisture discharge shutter can be adjusted. The control part uses a slide system for easy adjustment.
Equipped with low-noise axial fan
A quiet axial flow fan is used, and the only noise during drying is the quiet fan. Quiet axial fan makes only a quiet fan noise during drying, allowing for quiet drying even at night.
Equipped with 200V electric heater
Three-phase 200V power supply. Digital control displays temperature inside the drying room, drying time, and setting time. Temperature is maintained at a constant level by a built-in sensor.
30 half trays (600mm x 600mm)
Each tray holds 2 to 3.5 kg. 30 trays can dry up to 105 kg. (Varies depending on the dried material.)
Equipped with casters as standard
The main unit is equipped with casters for smooth movement. The main unit is equipped with casters for smooth movement and easy layout changes.
LCD touch panel (PRO only)
Graphs can be displayed and temperature, time, air volume, and damper can be freely programmed.
Stainless steel cleaning tray
The stainless steel tray on the bottom can be easily removed for cleaning.
Stainless steel SUS304
The main unit is made of stainless steel SUS304, which is resistant to drying marine products and objects with high salt content. It is also highly durable and hygienic.
SPECIFICATIONS
| Model | E-30HD(Premium) -S | E-30HD(Premium) -PRO |
|---|---|---|
| Power supply | Three-phase 200V , Connected capacity 30A | |
| Dimensions (mm) | Width 870 x Depth 1302 x Height 1700 | |
| Trays | 30 half trays | |
| Tray dimensions (mm) | 600 x 600 depth 30 | |
| Heat source | Electric heater (sheath heater) | |
| Air blower | Axial flow fan 300W | |
| Power consumption | 50 / 60Hz : 8765/8885W 6868W | 50 / 60Hz : 8950W |
| Operation box <Display> | Digital | LCD touch panel |
| Operation box <Temperature controller> | Thermistor | |
| Operation box <Timer> | End | Reserved, intermittent, end |
| Operation box <Air volume adjustment> | - | 〇 |
| Operation box <Auto temperature increase> | - | 10 to 100 steps temperature increase 30 patterns program |
| Air intake and exhaust | Manual ( 5-step changeover) | AUTO |
| Drying chamber material | SUS304 | |
| Drying Method | Circulation type box type | |
| Body weight (kg) | 237 | 241 |
| Drying processing capacity (kg) | 60-105 (fresh shiitake conversion) | |
